In this post we explain how to convert from Bandwidth (Hz/kHz/MHz/GHz) to Data throughput in terms of Bits per second (bps/kbps/Mbps/Gbps).
To calculate the bit rate we use the Shannon-Hartley formula
C = B*Log2(1 + S/N)
- C is the throughput in bits per second
- B is the bandwidth in Hz
- S/N is the signal-to-noise ratio
In the calculator below, enter the bandwidth and the SNR (dB)
Mbps to MHz
The Shannon-Hartley formula makes the following assumptions:
- The noise is white Gaussian. In other words it does not consider the effect of Fading which can cause additional signal losses.
- The throughput in bit-per-second is an upper bound. It represents an ideal condition that can be achieved with an arbitrarily low error rate.
- For 100 MHz of bandwidth and 10 dB Signal to noise ratio, the maximum throughput is 346 Mbps. Throughput increases with SNR. For instance at 15 dB SNR, the max data rate is 503 Mbps.
